جزئیات محصول:
|
| مواد خام فولادی: | Q235B، Q355B، ASTM A36 | درمان سطحی: | نقاشی، گالوانیزه داغ |
|---|---|---|---|
| عمر سرویس: | 50 سال | دیوار و سقف: | ورق روکش فلزی ، پنل ساندویچ |
| ستون ها و تیرها: | فولاد H | سطح انفجار شات: | Sa 2.5 |
| گواهی: | CE, AISC, SGS, BV, ISO, GB | نصب و راه اندازی: | راهنمایی مهندس در سایت |
| طراحی: | CAD، Tekla، مدل 3D، Pkpm، Bim | کد Hs: | 9406900090 |
| بسته حمل و نقل: | بسته صادرات استاندارد یا نیاز مشتری | ظرفیت تولید: | 30000ton/سال |
| ویژگی ها: | ساختار فولاد prefab ، دهانه بزرگ ، چند طبقه | فرم اتصال: | اتصال پیچ |
| دیوار پاراپت: | همانطور که درخواست شد | ||
| برجسته کردن: | Q355B steel warehouse,prefabricated steel warehouse,sandwich panel steel structure |
||
| Component | Specification |
|---|---|
| Main Steel Frame (Column) | Q235, Q355 Welded H Section Steel |
| Main Steel Frame (Beam) | Q235, Q355 Welded H Section Steel |
| Purlin | Q235 C and Z purlin |
| Knee bracing | Q235 Angle Steel |
| Tie Bar | Q235 Circular Steel Pipe |
| Bracing | Q235 Round Bar |
| Column and Horizontal Bracing | Q235 Angle Steel, Round Bar or Steel Pipe |
| Roof Panel | EPS Sandwich Panel / Fiber Glass Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet |
| Wall Panel | Sandwich Panel / Corrugated Steel Sheet |
| Window | Aluminium Alloy Window / PVC Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
| Downspout | PVC |
| Structure Usage | Up to 50 years |
| Finishing Options | Vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) or galvanized. |
Service Advantages
